Deskripsi Produk
We are a professional manufacturer of high-performance Feedthrough Capacitor Filters, also known as Tubular Ceramic Capacitors. Our components provide effective electromagnetic interference (EMI) suppression across diverse electronic applications, with a focus on quality and customization for automotive, telecommunications, industrial, and military sectors.
Key Features
  • Excellent Insertion Loss: High insertion loss across broad frequency spectrum (10 KHz to over 10 GHz) for reliable noise filtering
  • Diverse Range of Options: Various series for different installation requirements including Resin Sealed Bolt-in Filters (Metric sizes M2.5, M4, M5, M6, M8, M10) and standard thread series (UNF, UNC, UNEF)
  • Multiple Dielectric Materials: Available in NP0, SL, X7R, Y5V, and Y5U dielectrics for different capacitance, temperature stability, and voltage requirements
  • Customization Available: We accept sample drawing customization to tailor products to your specific mechanical and electrical needs
  • Robust Construction: Available with silver or nickel plating and various termination styles for reliable performance and easy installation
Electrical Parameters
Parameter Range
Rated Voltage (DC) 50V to 700V and higher
Capacitance Range From a few pico farads (pF) up to several microfarads (μF)
Current Rating (I) Options for different current requirements, including high-current PI (Power Integrity) filters
Product Series
Tubular & Resin Sealed Types
Ideal for bolt-in mounting, offering compact and robust filtering solutions.
Threaded Filters (UNF, UNC Series)
Designed for easy integration into panels and enclosures with standard threading (e.g., 1/4-28UNF, 6-32UNC, M12 threads), providing excellent chassis grounding.
Applications
  • Power Supply Units
  • Communication Equipment (Base Stations, Routers)
  • Industrial Automation and Drives
  • Medical Electronics
  • Test and Measurement Instruments
  • Military and Aerospace Systems
  • Automotive Electronics
Why Choose Us?
With years of experience in passive component manufacturing, we ensure product reliability and consistency. Our ability to offer custom solutions based on sample drawings makes us a flexible and valuable partner for your design and production needs. Contact us for a quote or to discuss your specific filter requirements.
